TBC-36SD-GF-N

Key Features

Super Deluxe Glass Chiller & Froster, 36-3/4″W x 26-1/2″D x 33-1/4″H, 9.74 cu.ft., self-cleaning condenser equipped, side mount, self-contained, (5) PE coated durable shelves, (1) sliding lid, stainless steel countertop & lid, stainless steel exterior, stainless steel inside walls & floor, galvanized steel interior top, (5) casters standard, R290 Hydrocarbon refrigerant, 1/3 HP, 115v/60/1-ph, 1.6 amps, cord with NEMA 5-15P, cETLus, ETL-Sanitation

Warranty

  • 5 Year Parts & Labor
  • 7 Year Compressor Warranty

Documents

new-message Features

Self-Cleaning Condenser
The accumulation of dust in the condenser can cause failures and/or breakdowns in refrigeration. Refrigerators operate normally until they accumulate a certain amount of dust. When they reach over their limit, performance drops rapidly, resulting in damage to or possible disposal of stored products in the refrigerators. The Self-Cleaning Condenser device keeps the condenser clean and prevents system failure by automatically brushing daily.

Hydrocarbon Refrigerants (R-290)
With innovative and eco-friendly technology, Turbo Air brings you hydrocarbon refrigerators designed to meet DOE’s Energy Conservation Standards in 2017 and to use EPA’s SNAP Program approved HC refrigerants. Hydrocarbon refrigerants do not deplete the ozone layer and have very low contribution to global warming (ODP-0, GWP-3).

Stainless steel cabinet construction
Super Deluxe (SD) models boast a stainless steel exterior (except galvanized steel back and bottom). SB models have an attractive wear-resistant black vinyl exterior. Heavy gauge stainless steel countertop and glide lids are perfect for sanitation and durability. Interior is stainless steel except galvanized steel top. Turbo Air Glass Froster model guarantees utmost in cleanliness and long product life. It also adds a touch of style to the most refined setting.

High-density polyurethane insulation
The entire cabinet structure is foamed-in-place using high density, HCFC free polyurethane insulation.

Heavy duty, PE (polyethylene) coated dividers
Heavy duty 10mm thick pure grade PE coated shelves are provided for maximum storage use.

Side mount compressor unit
With compressors positioned on the side of the unit, our refrigerators can now be serviced without being moved. Our innovative, front air intake feature also allows this model to be highly efficient in narrow spaces.

Manual defrost system

Direct cooling type

Large capacity cooler cabinet requires only minimum floor space

Glass / mug froster holds -5°F ~ 15°F for the best in chilling glasses and plates

STANDARD FEATURES
• Anti-corrosion coated evaporator
• Self-contained system
• 2.5” dia. swivel casters with locks on the front set
• Door locks

Warning: This product can expose you to chemicals including Bisphenol A(BPA) and Di (2-ethylhexyl) phthalate (DEHP) and Cobalt sulfate heptahydrate, which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, go to www.p65warnings.ca.gov.

nuts Parts & Accessories

OPTIONAL ACCESSORIES
• 1” caster, ½” diameter & 13 TPI: S28R813660 (non-brake)
• 2” caster for underbar series, ½” diameter: P0165B0100 (non-brake), P0165B0110 (w/ brake)
• 4” caster, ½” diameter & 13 TPI: 30265L0400 (non-brake), 30265L0300 (w/ brake)
• 5” caster, ½” diameter & 13 TPI: M726500100 (non-brake), M726500200 (w/ brake)
• Leveling leg, ½” – 13 TPI x 1.54”: LFM1213566
• 6” adjustable stainless steel leg: P0121P0100
